SGT-MOSFET采用国际先进的工艺技术,目前已开发出25V~100V的SGT-MOS平台,正在开发150V SGT-MOS平台。
采用独特的版图和结构设计,提高芯片功率密度以及可靠性,基于卓越的研发及设计能力,低电压SGT产品已成功实现目前国内同级产品中最优水平的综合性能。
SGT-MOS的主要应用为开关电源、DC-DC转换器、马达控制等。
Product | Package | Configuration | Polarity | VDS | ID | VGS | VGS(th) | RDS(on)@ 4.5V | RDS(on)@10V | Qg | |||
Min. | Max. | Typ. | Max. | Typ. | Max. | Typ. | |||||||
V | A | V | V | V | mΩ | mΩ | mΩ | mΩ | nC | ||||
JMV3708NA | DFN 3.3x3.3 | Single | N | 25 | 80 | ±10 | 0.4 | 1.2 | 1.7 | 2.2 | - | - | 28.1 |
JMV3809N | DFN 3.3x3.3 | Single | N | 25 | 22 | ±10 | 0.4 | 1.2 | 9 | 11.7 | - | - | 5.5 |
JMT3801N | DFN 3.3x3.3 | Dual | N | 25 | 24 | ±10 | 0.4 | 1.2 | 9.8 | 12 | - | - | 8.9 |
JMM4719ND | DFN 5x6 | Single | N | 30 | 173 | ±20 | 1.1 | 2.2 | 1.2 | 1.55 | 0.85 | 1.05 | 107 |
JMM4719N | DFN 5x6 | Single | N | 30 | 173 | ±20 | 1.1 | 2.2 | 1.2 | 1.55 | 0.85 | 1.05 | 107 |
JMV4720ND | DFN 3.3x3.3 | Single | N | 30 | 75 | ±20 | 1.1 | 2.2 | 2.9 | 3.7 | 1.9 | 2.4 | 32 |
JMM4720N | DFN 5x6 | Single | N | 30 | 70 | ±20 | 1.1 | 2.2 | 3.1 | 4 | 2.1 | 2.7 | 32 |
JMV4708ND | DFN 3.3x3.3 | Single | N | 30 | 75 | ±20 | 1.1 | 2.2 | 2.9 | 3.7 | 1.9 | 2.4 | 29.5 |
JMV4708ND | DFN 3.3x3.3 | Single | N | 30 | 75 | ±20 | 1.1 | 2.2 | 2.9 | 3.7 | 1.9 | 2.4 | 29.5 |
JMM4708ND | DFN 5x6 | Single | N | 30 | 75 | ±20 | 1.1 | 2.2 | 3 | 3.8 | 2 | 2.5 | 29.5 |
JMM4708N | DFN 5x6 | Single | N | 30 | 73 | ±20 | 1.1 | 2.2 | 3.1 | 4 | 2.1 | 2.7 | 29.5 |
JMM4808N | DFN 5x6 | Single | N | 30 | 70 | ±20 | 1.1 | 2.2 | 3.3 | 4.2 | 2.3 | 2.9 | 29.5 |
JMV4808N | DFN 3.3x3.3 | Single | N | 30 | 66 | ±20 | 1.1 | 2.2 | 3.6 | 4.6 | 2.6 | 3.3 | 29.5 |
JMD4808N | TO-252 | Single | N | 30 | 74 | ±20 | 1.1 | 2.2 | 3.7 | 4.7 | 2.7 | 3.4 | 29.5 |
JMP4708N | TO-220 | Single | N | 30 | 70 | ±20 | 1.1 | 2.2 | 3.9 | 5 | 2.9 | 3.7 | 29.5 |
JMV4812N | DFN 3.3x3.3 | Single | N | 30 | 43 | ±20 | 1.1 | 2.2 | 6.5 | 8 | 4.1 | 5 | 17.4 |
JMM4812N | DFN 5x6 | Single | N | 30 | 43 | ±20 | 1.1 | 2.2 | 6.5 | 8 | 4.1 | 5 | 17.4 |
JMD4812N | TO-252 | Single | N | 30 | 36 | ±20 | 1.1 | 2.2 | 7.1 | 8.9 | 4.7 | 6.1 | 17.4 |
JMM4716N | DFN 5x6 | Single | N | 30 | 21 | ±20 | 1.1 | 2.2 | 10.6 | 13.8 | 6.6 | 8.6 | 10.9 |
JMS4710N | DFN 3x3 | Dual | N | 30 | 18 | ±20 | 1.1 | 2.2 | 13.3 | 17.2 | 8.3 | 10.7 | 8.8 |
JMS4710N | DFN 3x3 | Dual | N | 30 | 18 | ±20 | 1.1 | 2.2 | 10.9 | 14.1 | 6.9 | 8.9 | 10.9 |
JMM5770N | DFN 5x6 | Single | N | 40 | 132 | ±20 | 1.1 | 2.2 | 1.4 | 1.8 | 1.1 | 1.4 | 97 |
JMM5770ND | DFN 5x6 | Single | N | 40 | 138 | ±20 | 1.1 | 2.2 | 1.4 | 1.8 | 1.1 | 1.4 | 97 |
JMP5770N | TO-220 | Single | N | 40 | 113 | ±20 | 1.1 | 2.2 | 2 | 2.6 | 1.6 | 2.1 | 97 |
JMM5771N | DFN 5x6 | Single | N | 40 | 81 | ±20 | 1.1 | 2.2 | 2.8 | 3.6 | 2.1 | 2.6 | 46 |
JMV5772ND | DFN 3.3x3.3 | Single | N | 40 | 63 | ±20 | 1.1 | 2.2 | 3.8 | 4.9 | 2.8 | 3.4 | 39 |
JMM5772N | DFN 5x6 | Single | N | 40 | 61 | ±20 | 1.1 | 2.2 | 4 | 5.2 | 3 | 3.6 | 39 |
JMV5751N | DFN 3.3x3.3 | Single | N | 40 | 39 | ±20 | 1.1 | 2.2 | 7.5 | 9.8 | 5 | 6 | 15.3 |
JMM6715N | DFN 5x6 | Single | N | 60 | 79 | ±20 | 1.2 | 2.2 | 3.4 | 4.4 | 2.4 | 2.9 | 54 |
JMM6715ND | DFN 5x6 | Single | N | 60 | 77 | ±20 | 1.2 | 2.2 | 3.6 | 4.7 | 2.6 | 3.1 | 54 |
JMM6716N | DFN 5x6 | Single | N | 60 | 96 | ±20 | 1.2 | 2.2 | 2.2 | 2.8 | 1.8 | 2.4 | 89 |
JMM6716ND | DFN 5x6 | Single | N | 60 | 104 | ±20 | 1.2 | 2.2 | 2.2 | 2.8 | 1.8 | 2.4 | 89 |
JMP6716N | TO-220 | Single | N | 60 | 94 | ±20 | 1.2 | 2.2 | 2.6 | 3.4 | 2.1 | 2.7 | 89 |
JMM8701N | DFN 5x6 | Single | N | 100 | 94 | ±20 | 1.5 | 2.5 | 5.3 | 6.9 | 4.2 | 5 | - |
JMP8701N | TO-220 | Single | N | 100 | 89 | ±20 | 1.5 | 2.5 | 5.8 | 7.5 | 4.7 | 5.6 | - |
JMG8701N | TO-263 | Single | N | 100 | 89 | ±20 | 1.5 | 2.5 | 5.8 | 7.5 | 4.7 | 5.6 | - |
