采用深沟槽工艺，为国内目前元胞尺寸最小的SJ-MOS产品之一。
采用独特的终端设计，在有效减小芯片面积的同时实现了器件的高可靠性。
基于SJ-MOS的技术特点，其主要应用于PD充电、LED电源、服务器电源，电动汽车充电桩等。
| Product | Package | Polarity | VDS | ID | VGS | VGS(th) | RDS(on)@ 10V | ||
| Min. | Max. | Typ. | Max. | ||||||
| V | A | V | V | V | mΩ | mΩ | |||
| JMH60R080S | TO-247 | N | 600 | 42 | ±30 | 2.5 | 4.5 | 65 | 80 |
| JMH60R080F | TO-247 | N | 600 | 42 | ±20 | 2.5 | 4.5 | 65 | 80 |
| JMP60R160S | TO-220 | N | 600 | 22 | ±30 | 2.5 | 4.5 | 125 | 160 |
| JMG60R160S | TO-220MF | N | 600 | 11 | ±30 | 2.5 | 4.5 | 125 | 160 |
| JMG60R160F | TO-220MF | N | 600 | 11 | ±20 | 2.5 | 4.5 | 125 | 160 |
| JMG60R320S | TO-220MF | N | 600 | 11 | ±30 | 2.5 | 4.5 | 270 | 320 |
| JMD60R320S | TO-252 | N | 600 | 12 | ±30 | 2.5 | 4.5 | 270 | 320 |
| JMN60R320S | DFN 8x8 | N | 600 | 11 | ±30 | 2.5 | 4.5 | 270 | 320 |
| JCD60R380S | TO-252 | N | 600 | 11 | ±30 | 2.5 | 4.5 | 318 | 380 |
| JCF60R380S | TO-220F | N | 600 | 9.6 | ±30 | 2.5 | 4.5 | 318 | 380 |
| JMH65R100S | TO-247 | N | 650 | 35 | ±30 | 2.5 | 4.5 | 80 | 100 |
| JMP65R100F | TO-220 | N | 650 | 25 | ±20 | 2.5 | 4.5 | 80 | 100 |
| JMH65R100F | TO-247 | N | 650 | 35 | ±20 | 2.5 | 4.5 | 80 | 100 |
| JMP65R190S | TO-220 | N | 650 | 20 | ±30 | 2.5 | 4.5 | 150 | 190 |
| JMG65R190S | TO-220MF | N | 650 | 10 | ±30 | 2.5 | 4.5 | 150 | 190 |
| JMG65R380S | TO-220MF | N | 650 | 9 | ±30 | 2.5 | 4.5 | 320 | 380 |
| JMD65R380S | TO-252 | N | 650 | 10 | ±30 | 2.5 | 4.5 | 320 | 380 |
| JMN65R380S | DFN 8x8 | N | 650 | 9.6 | ±30 | 2.5 | 4.5 | 320 | 380 |
